Types of Network designing Connections

Computer networks can be broken down historically into topologies, which is a technique of connecting computers. The most common topology today is a collapsed ring. This is due to the success of a network protocol called the Ethernet. This protocol, or a network language, supports the Internet, Local Area Networks, and Wide Area Networks.

Bus Topology

this is another type of design where a single cable connects all computers and the information intended for the last node on the network must run through each connected computer. If a cable is broken, all computers connected down the line cannot reach the network. The benefit of a bus topology is a minimal use of cabling.

Collapsed Ring Topology

A similar topology is called a ring. In this design, computers are connected via a single cable, but the end nodes also are connected to each other. In this design, the signal circulates through the network until it finds the intended recipient. If a network node is not configured properly, or it is down temporarily for another reason, the signal will make a number of attempts to find its destination.

 collapsed ring is a topology where the central node is a network device called a hub, a router, or a switch. This device runs a ring topology internally and features plugins for cables. Next, each computer has an independent cable, which plugs into the device. Most modern offices have a cabling closet, or a space containing a switch device that connects the network. All computers in the office connect to the cabling closet and the switch. Even if a network plug is near a desk, the plug is connected via a cable to the cabling closet.

Star Topology

A star topology is a design of a network where a central node extends a cable to each computer on the network. On a star network, computers are connected independently to the center of the network. If a cable is broken, the other computers can operate without problems. A star topology requires a lot of cabling.

Cable Types

Cables are conductive media that allow the signal to flow. The signal can be an electric pulse or a light flicker. The type of signal carried through the cable is defined by the material the cable is made out of. All cables have a limitation as to how far they can carry a signal without a natural process of signal loss called attenuation.

Coaxial cable, often used for cable television, features a central copper wire and many layers of insulation. The cable can carry the Internet connectivity along with other information.
